A-6 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Belt
Scale
Code
Scale
Model
Belt
Width
Calibr.
Kit
# Load Cells
# Idlers
LA
LB1 LB2 LB3 LB4 LB5 LB6
LC LD LE LF LG
mV/
V
120 2 2 110 30 90 0 0 0 0 130 60 -4.5 6.5 7 3
121
122
123 2 2 72.17 19.69 59.06 0 0 0 0 85.28 39.37 -4.5 6.5 7 3
124 2 2 86.61 23.62 70.87 0 0 0 0 102.36 47.24 -4.5 6.5 7 3
125
126
127
128
129
130 2 4 58.12 16.5 49.5 16.5 49.5 0 0 58.12 33 -4.5 6.5 7 3
131 2 4 64.12 18 54 18 54 0 0 64.12 36 -4.5 6.5 7 3
132 2 4 72.12 20 60 20 60 0 0 72.12 40 -4.5 6.5 7 3
133 2 4 76.12 21 63 21 63 0 0 76.12 42 -4.5 6.5 7 3
134 2 4 88.12 24 72 24 72 0 0 88.12 48 -4.5 6.5 7 3
135 2 4 100.12 27 81 27 81 0 0 100.1 54 -4.5 6.5 7 3
136 2 4 112.12 30 90 30 90 0 0 112.1 60 -4.5 6.5 7 3
137
138
139 2 4 70.87 19.69 59.06 19.69 59.06 0 0 70.87 39.37 -4.5 6.5 7 3
140 2 4 86.61 23.62 70.87 23.62 70.87 0 0 86.61 47.24 -4.5 6.5 7 3
201 1 1 31.89 24.02 0 0 0 0 0 24.02 39.37 -
16.81
6.38 4.92 3
202 1 1 31.89 24.02 0 0 0 0 0 24.02 39.37 -
16.81
4.41 4.92 3
203 1 1 31.89 24.02 0 0 0 0 0 24.02 19.69 -
16.81
6.38 4.92 3
204 1 1 31.89 24.02 0 0 0 0 0 24.02 19.69 -
16.81
4.41 4.92 3
205 2 1 31.89 24.02 0 0 0 0 0 24.02 39.37 -
16.81
6.38 4.92 3
206 2 1 31.89 24.02 0 0 0 0 0 24.02 39.37 -
16.81
4.41 4.92 3
207 1 2 31.89 24.02 24.02 0 0 0 0 24.02 39.37 -
16.81
6.38 4.92 3
208 2 2 31.89 24.02 24.02 0 0 0 0 24.02 39.37 -
16.81
6.38 4.92 3
209 1 1 0 0 0 0 0 0 0 0 39.37 0 0 0 2
210
1
1
0
0
0
0
0
0
0
0
23.62
0
0
0
2
211
2
1
0
0
0
0
0
0
0
0
47.24
0
0
0
2
212 4 4 0 0 0 0 0 0 0 0 39.37 0 0 0 2
213
4
3
0
0
0
0
0
0
0
0
39.37
0
0
0
2
214
10-101R-1
50-30
1
1
0
0
0
0
0
0
0
0
39.37
0
0
0
2
215 10-101R-2 50-30 2 1 0 0 0 0 0 0 0 0 39.37 0 0 0 2
301
1
1
39.37
31.50
0
0
0
0
0
25.59
39.37
-6.42
5.43
5.31
3
302 1 1 39.37 31.50 0 0 0 0 0 25.59 47.24 -6.42 5.43 5.31 3
303
1
1
39.37
31.50
0
0
0
0
0
25.59
39.37
-8.39
7.40
6.30
3
