Initializing the Micro-Tech
Acquiring Basic System Data
Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J 2-5
You are now ready to measure the belt speed of your conveyor system.
Go to page 2-10.
Here is a list of belt-scale codes for pivoting scales. (For a complete list
of belt-scale codes, see Table A–1 in Appendix A.)
Pivoting belt-scale codes*: 0–42, 54–59.
(* Please note that this is not an exhaustive list, because newer or
custom scales are not listed.)
We suggest you print or photocopy this page and insert the required data into the table below.
Doing so will save you considerable time when you come to initialize the Micro-Tech software.
Table 2–2. Initialization Data Sheet (Pivoting)
Parameter*
Details of Your
Particular System
Defaults from
Table A–1, or other
Pivot-to-load cell distance (inches) 32
Number of weight idlers 1
Pivot-to-first-idler distance (inches) 24
Pivot-to-test weight height (inches) 0
Pivot-to-test weight length (inches) 24
Pivot-to-carriage height (inches) 6.5
Roller-to-carriage height (inches) 6.5
Number of load cells 1
Idler spacing (inches) 36
Conveyor angle (degrees) 0
Load-cell capacity (lbs.) 250
Load-cell sensitivity (mV/V) 3.0
Load-cell resistance, #1 (ohms) 350
Type of speed input —
Belt length (feet) —
Time for one belt revolution (seconds) —
Number of revolutions for test >3
Time to complete test revolutions (seconds) —
* The example above, including the defaults, is for belt-scale code 1. Your weighing system will,
most likely, have a slightly different list of required parameters and defaults.
