Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-61
Register Name Comments
Register Start
Number
OffSet
Free Space
Scale 2
124
248
Free Space
Scale 2
126
252
Free Space Scale 2 128 256
Scale 1 Table
N10:X F11:X N12:X F13:X
0 Success_Flag Span Number Number Of trials Scale Capacity
1 Status_LED Scale Capacity Command Speed Capacity
2 Status Speed Capacity Command Load Cell Capacity
3 Status Load Cell Capacity Last Key Pressed Batch Setpoint
4 Status Rate Batch Number Batch Preset
5 Status Load Batch Deviation Batch Preact
6 Alarms Speed FREE SPACE Auto Zero Max Dev
7 Alarms Master Total FREE SPACE AZT step limit
8 Alarms Reset Total FREE SPACE Belt Warm
9 Alarms Operator Total FREE SPACE High Rate Set
10 Alarms Batch Total FREE SPACE Low Rate Set
11 Alarms Batch Setpoint FREE SPACE High Speed Set
12 I/O Batch Preset FREE SPACE Low Speed Set
13 I/O Batch Preact FREE SPACE High Load Set
14 I/O AZT Correction FREE SPACE Low Load Set
15 I/O Auto Zero Max Dev FREE SPACE FREE SPACE
16 I/O Total AZ % NOT USED FREE SPACE
17 I/O AZT step limit NOT USED FREE SPACE
18 I/O Belt Warm NOT USED FREE SPACE
19 I/O High Rate Set NOT USED FREE SPACE
20 I/O Low Rate Set NOT USED FREE SPACE
21 I/O High Speed Set NOT USED FREE SPACE
22 I/O Low Speed Set NOT USED FREE SPACE
23 I/O High Load Set NOT USED FREE SPACE
24 Number Of Trials Low Load Set NOT USED FREE SPACE
25 Model ID Cal Error NOT USED NOT USED
26 Batch Number FREE SPACE NOT USED NOT USED
27 Batch Deviation FREE SPACE NOT USED NOT USED
28 AZ Deviation FREE SPACE NOT USED NOT USED
29 AZ Deviation FREE SPACE NOT USED NOT USED
30 Zero Number FREE SPACE NOT USED NOT USED
PLC 5 Data Tables
