Specifications
1-20 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Here is a table showing the relevant technical specifications for the
Micro-Tech.
Table 1–2. Micro-Tech Technical Specifications
Description Specification
Field Mount Enclosure NEMA 4X, IP66, dust and watertight, 17.01 [432] x 14.18 [360] x
6.59 [167] inches. Fiberglass reinforced polyester.
Steel chassis providing EMI/RFI shielding.
Panel Mount Enclosure Size: 12.11 [308] x 4 [102] x 7.95 [202] inches.
Material: Zinc-plated mild steel.
Environmental Conditions Mounting Should be mounted as close to the load cells as possible without
being exposed to excessive heat or moisture.
Field Mount suitable for outdoor mounting.
Temperature (Ambient) Storage: -22° to +158° F (-30° to +70° C).
Operating: –4° to +140° F (-20° to +60° C).
Relative Humidity Maximum relative humidity 80% for temperatures up to 31°C
decreasing linearly to 50% humidity at 40°C.
Pollution Degree Level 2 per IEC 61010-1
Altitude Up to 6,561 ft (2000m)
Installation Category 2
Shock 15G peak for 11ms duration (±1.0 ms)
Vibration 0.006 in./0.152 mm displacement, 1G peak
Emission Limitation According to IEC/EN 61326-1, Class A
Noise Immunity According to IEC/EN 61326-1, Industrial Environmental
Nominal Voltage Field Mount: 100 - 240 VAC.
Panel Mount: 24VDC +10%,-15% (user supplied).
Nominal Frequency Field Mount: 50-60 Hz.
Panel Mount: DC only.
Fusing 250VAC, 2A fast acting, on motherboard
Power Consumption 50 VA max.
Maximum Non-Destructive Input Voltage Field Mount: 265 VAC.
Panel Mount: 28VDC.
DC Power Supply Required for Panel Mount Output voltage: 24 VDC.
Isolation: No.
Output current: 2A minimum, short circuit protected.
