Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J B-25
No.
Parameter
Selection
Description
9B Load cell #2 res. 350.000 Ohms
(10-2000)
Signal bridge resistance of load cell #2.
Note: Scale model dependent.
9C
Load cell #3 res.
350.000 Ohms
(10-2000)
Signal bridge resistance of load cell #3.
Note: Scale model dependent.
9D
Load cell #4 res.
350.000 Ohms
(10-2000)
Signal bridge resistance of load cell #4.
Note: Scale model dependent.
9E Load cell #5 res. 350.000 Ohms
(10-2000)
Signal bridge resistance of load cell #5.
Note: Scale model dependent.
9F
Load cell #6 res.
350.000 Ohms
(10-2000)
Signal bridge resistance of load cell #6.
Note: Scale model dependent.
10
Speed input
Single, dual,
simulated
Informs the Micro-Tech where the speed input is
physically wired (or not wired, in the case of simulated).
11
Zero dead-band
range
0.0 % (0-5%)
Low level threshold where Rate and Totalization are
stopped.
12
W&M mode
NONE, NTEP,
OIML
Weights & Measures Mode
13
Load-cell balance
100 (1-100 %)
Here is the Calibration Data menu table.
No.
Parameter
Selection
Description
1
Calibration mode
R-Cal, Chain, Weights
Selecting simulated calibration mode
2
R-Cal selected Res
165000 Ohms (10-
1,000,000)
Ohms value of calibration resister
3
R-Cal constant
Calculated (or factored) accumulated weight
at end of simulated Rcal calibration
4
Chain select. weight
0.000 lb/ft (0.0 - 1000)
Stamped weight per length of calibration
chain(s).
5
Chain cal constant
Calculated (or factored) accumulated weight
at end of simulated Chain calibration
Calibration Data
Menu
