Thermo Scientific Micro-Tech 9101 - Description of Registers

Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-9
Register Name Multi Scale
Read/
Write
Low
Limit
High
Limit
Refresh
Time
[ms]
Protection Format Length
Batch Preact
Scale Specific
RW
0
10000
limited
Float
2
AZT Correction
Scale Specific
R
0
0
none
Float
2
Auto Zero Max Dev Scale Specific RW 0 50 Service Float 2
Total AZ % Scale Specific R 0 0 none Float 2
AZT step limit
Scale Specific
RW
0
10
none
Float
2
Belt Warm
Scale Specific
RW
0
160
none
Float
2
High Rate Set Scale Specific RW 0 150 limited Float 2
Low Rate Set Scale Specific RW 0 105 limited Float 2
High Speed Set
Scale Specific
RW
0
200
limited
Float
2
Low Speed Set Scale Specific RW 0 105 limited Float 2
High Load Set Scale Specific RW 0 150 limited Float 2
Low Load Set Scale Specific RW 0 105 limited Float 2
Cal Error
Scale Specific
R
0
0
none
Float
2
Master Total Double
Scale Specific
R
0
0
none
Double
4
Reset Total Double Scale Specific R 0 0 none Double 4
Operator Total Double Scale Specific R 0 0 limited Double 4
Batch Total Double
Scale Specific
R
0
0
limited
Double
4
This section tells you more about each of the registers (such as the status,
alarm, or speed registers) listed above.
Register Name Description
Success_Flag
Set to 0 after a message has been received and properly processed. If a message
is correctly received but cannot be processed because password protection or size
error, this flag is set to 1. The user may read this register after a write message to
ensure the data has been accepted.
Display
Contains the messages actually shown on the display of the instrument in form of
an ASCII string. See Display Table.
Status LED
See Status Table on page C-11.
Status See Status Table on page C-11.
Alarms See Alarm Table on page C-13.
I/O See I/O Table on page C-15..
Number Of trials
The number of audit trails to print. Entered or downloaded by the user. An integer
value 1 to 999.
