C-8 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
This section defines the type, limits, and format of registers.
NOTE. The actual address of each register is defined differently for each
protocol, as explained in the following sections.
Table C–1. Type, Limits, and Format of Registers
Register Name Multi Scale
Read/
Write
Low
Limit
High
Limit
Refresh
Time
[ms]
Protection Format Length
Success_Flag Common R none Integer 1
Status Scale Specific R 0 0 100 Integer 4
Alarms Common R 0 0 100 Integer 6
I/O Common R 0 0 100 Integer 12
Last Key Pressed Common W 0 32767 Integer 1
Model ID Common R 0 100 Integer 1
AZ Deviation Scale Specific R 0 10000000 none Long 2
Zero Number Scale Specific R 0 100 none Long 2
Set/Res Out # Common W 0
Installed
Output
Number
Integer 1
Set/Res Out # Common W 0
Integer 1
Set/Res Out # Common W 0
Integer 1
Set/Res Out # Common W 0
Integer 1
Span Number Scale Specific R 0 100 none Float 2
Scale Capacity Scale Specific RW 1 200,000 Service Float 2
Rate Scale Specific R 0 0 100 Float 2
Load Scale Specific R 0 0 100 Float 2
Master Total Scale Specific R 0 0 100 none Float 2
Reset Total Scale Specific RW 0 0 100 none Float 2
Operator Total Scale Specific RW 0 0 100 limited Float 2
Batch Preset Scale Specific RW 0 10000 limited Float 2
