B-10 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
R-Cal Span Calibration is described in “Chapter 3 – Operation” (see
page 3-7). Chain and Weights Span Calibrations follow a similar
procedure to R-Cal and can be performed by following the screen
instructions. In addition, the following instructions should be noted:
1. Make sure the calibration method is set to the appropriate method
(weights or chains) as described above.
2. Make sure the conveyor belt is stopped before applying the weights
or chains.
CAUTION. Do not apply weights or chains until instructed to do so by
the Micro-Tech.
3. When using the weight calibration procedure, if you selected “Load
WTS” in the “I/O Definition Menu” (see page B-38), the following
screen appears.
With the “Load WTS” option selected, the test weights are
automatically loaded after you press the Start button. Wait for the
test weights to be loaded, before proceeding to the next step.
Span Calibration
Instructions
Press START to load
the test weights
To Next Page
Loading...
