Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-77
Block “2” is the Read block that contains all the registers relevant to Sets
and Thresholds.
Table C–10. READ BLOCK 2: Sets and Thresholds
Register Start
Offset
Start
Number Of trials
5
Zero Reference
6
AZ Deviation
7
Scale Capacity
9
Speed Capacity
11
Load Cell Capacity
13
AZT Correction
15
Auto Zero Max Dev
17
Total AZ %
19
AZT step limit
21
Belt Warm
23
High Rate Set
25
Low Rate Set
27
High Speed Set
29
Low Speed Set
31
High Load Set
33
Low Load Set
35
Block “100” is the Write block that is used to drive (set-reset) outputs as
well as to send Commands to the Micro-Tech.
Table C–11. WRITE BLOCK 100: Commands
Register
Name
Offset
Start
Commands 5
Last Key Pressed 7
Set/Res Out # 8
Set/Res Out # 9
Set/Res Out # 10
Set/Res Out # 11
Set/Res Out # 12
