Thermo Scientific Micro-Tech 9101 - Register Mapping; Block 0

C-76 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
This section contains the Profibus Register Mapping for the Micro-Tech.
Block “0” is the Read block that contains all the registers relevant to the
Status, Alarms, I/O and Dynamic data. It is the default group the Micro-
Tech sends to the master for a read request if the master does not change
request.
Table C–8. READ BLOCK 0: Status, Alarms, I/O, Dynamic data
Register Name
Offset
Start
Status LED 5
Status
6
Alarms 10
I/O 16
Model ID 28
Zero Number
29
Span Number 31
Rate 33
Load 35
Speed
37
Master Total 39
Reset Total 41
Operator Total 43
Cal Error 45
Block “1” is the Read block that contains all the registers relevant to the
Batch (Load out) function.
Table C–9. READ BLOCK 1: Batch (Load out) function
Register Name
Offset
start
Batch Number
5
Batch Deviation
6
Batch Total
7
Batch Setpoint
9
Batch Preset
11
Batch Preact
13
