Thermo Scientific Micro-Tech 9101 - Register Mapping

C-46 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Host (PLC) Slave (Micro-Tech)
10H
03H
20H →
← 10H
← 06H
10H →
05H →
01H
FFH →
← 10H
02H
02H
01H
4FH
00H
00H
00H
10H
03H
← AEH
10H →
06H →
The table below provides more details about the Allen-Bradley DF1
registers for Model 9101/9201.
Register Address Note
success_flag N7:0 0 successful, 1 failed.
display ( 1 ) N7:1
display ( 2 ) N7:2
display ( 3 ) N7:3
Register Mapping
