Thermo Scientific Micro-Tech 9101 - Motherboard Terminal Block Definitions

Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J A-23
The terminal-block definitions for the motherboard are shown below.
J16 J21 J45 J37 J29
1 2 3 4 5 6 7 11 12 13 14 15 16 17 21 22 23 24 25 26 31 32 33 34 35 36 37
38
41 42 43 44 45 46 47
48
LOADCELL 1 LOADCELL 2 COMM B COMM A SPU and
PULSE OUT
J16 Load Cell 1
1 SHIELD (EARTH)
2 + EXCITATION
3 – EXCITATION
4 + SENSE
5 – SENSE
6 + SIGNAL
7 – SIGNAL
J21 Load Cell 2
11 SHIELD (EARTH)
12 + EXCITATION
13 – EXCITATION
14 + SENSE
15 – SENSE
16 + SIGNAL
17 – SIGNAL
Motherboard
Terminal Block
Definitions
