B-22 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
No.
Parameter
Selection
Description
11 Damping Display
RATE
2 (0-400 sec) When process variables are displayed on the
screen, they can be damped by a
programmable factor to filter out variations
that can be introduced by mechanical
vibrations. To tune a damping filter, enter the
number of seconds corresponding to the
desired time constant.
For example, if 10 seconds is entered, the
process variable will reach stability after a
step change in 10 seconds. These damping
factors only affect the display, not the current
output variable.
(Password: Operator.)
12
Damping Display
LOAD
2 (0-400 sec)
"
Scroll available depending on DISPLAY
SCROLL 10 (Run Display, Line 3) setting.
13
Damping Displ.
SPEED
2 (0-400 sec)
"
Scroll available depending on DISPLAY
SCROLL 10 (Run Display, Line 3) setting.
14
L.C. Fail Time
Delay
2 (2-90 sec)
This timer starts when a load cell signal fail
alarm has been generated and after the timer
has elapsed the software forces a load cell
critical failure alarm.
(Password: Service.)
Here is the Scale Data menu table.
No.
Parameter
Selection
Description
1 Number of scales
1, 2
The Micro-Tech has the capability of supporting dual
scales with purchase of Dual Scale Option.
This scroll is not applicable to the 9201.
1A
Type of scale
One A/D Channel,
Two A/D Channel,
Four A/D
Channel*
Number of load cell input A/D channels being used.
*Available only when Dual A/D Board is installed.
This scroll is not applicable to the 9201.
1B
Load cell/s conn.
to
Channel 1 (J16),
Channel 2 (J21)
Scroll 1B is only present when One A/D Channel is
selected for Scroll 1A
This scroll is not applicable to the 9201.
2
Max Scale
Capacity
500 Tph (1 –
200000)
Max Scale Capacity.
Operating range 25 to 100%.
Scales the analog ma output (Rate and Load).
