Thermo Scientific Micro-Tech 9101 - Attached Drawings

G-2 Micro-Tech 9101/9201 Reference Manual Rev J Thermo Fisher Scientific
Attached Drawings
The following information is appended to the manual to help you install and maintain your Micro-Tech.
Description Document
Field-Wiring Diagrams
Micro-Tech 9101 D07392B-E020
Micro-Tech 9201 D07392B-E034
Analog I/O Board B07392B-E003
8-In/8-Out Digital Board B07392B-E005
Serial Communication C07392B-E008
Siemens Profibus Board C07392B-E011
Speed Sensors C07392B-E016
Communication Board C07392B-E017
Notes—Micro-Tech 9000 C07392B-E018
Digital Output Boards C07392B-E021
Anybus Comm for Device Net B07392B-E022
Digital Input Boards B07392B-E025
4–20mA Out Board B07392B-E026
Dual Plant LC A/D Board B07392B-E027
Premium A/D Board B07392B-E028
