C-78 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
Block “101” is the Write block used to manage the registers relevant to
the Batch (Load out) function.
Table C–12. WRITE BLOCK 101: Batch (Load out)
Register
Name
Offset
Word
Batch Number 5
Batch Deviation 6
Batch Set 7
Batch Preset 9
Batch Preact 11
Block “102” is the Write block used to manage the registers relevant to
Sets and Thresholds.
Table C–13. WRITE BLOCK 102: Sets and Thresholds
Register Name
Offset
Start
Number Of trials
5
Scale Capacity
6
Speed Capacity
8
Load Cell Capacity
10
Auto Zero Max Dev
12
AZT step limit
14
Belt Warm
16
High Rate Set
18
Low Rate Set
20
High Speed Set
22
Low Speed Set
24
High Load Set
26
Low Load Set
28
