Thermo Scientific Micro-Tech 9101 - Register Mapping

Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-27
Host (PLC) Slave (Micro-Tech)
00H
00H
10H
03H
99H
10H →
The table below provides more details about the Siemens 3964R registers
for the Model 9101/9201.
Register Address Notes
success_flag 20 H 0 successful, 1 failed.
display ( 1 ) 21 H
display ( 2 ) 22 H
display ( 3 ) 23 H
display ( 4 ) 24 H
display ( 5 ) 25 H
display ( 6 ) 26 H
display ( 7 ) 27 H
display ( 8 ) 28 H
display ( 9 ) 29 H
display ( 10 ) 2A H
display ( 11 ) 2B H
display ( 12 ) 2C H
display ( 13 ) 2D H
display ( 14 ) 2E H
display ( 15 ) 2F H
display ( 16 ) 30 H
display ( 17 ) 31 H
display ( 18 ) 32 H
display ( 19 ) 33 H
display ( 20 ) 34 H
