B-24 Micro-Tech 9101/9201 Reference Manual, Rev J Thermo Fisher Scientific
No.
Parameter
Selection
Description
4I Pivot to test-
weight height
0.00* ( -20 - 20
in)
On a pivoting scale with Model 50-30 static weight,
measurement from pivot to test weight height.
Note: Scale code dependent.
Note: Default value for Belt Scale code #1 shown.
4J
not used
4K
not used
4L
Pivot to test-
weight length
24.00* (0-10000
in)
On a pivoting scale with Model 50-30 static weight,
measurement from pivot to test weight length centerline.
Note: Scale code dependent.
Default value for Belt Scale code #1 shown.
4M
Pivot to carriage
height
6.50* (0-10 in)
On a pivoting scale with Model 50-30 static weight,
measurement from pivot to carriage height.
Note: Scale code dependent.
*Default value for Belt Scale code #1 shown.
4N
Roll to carriage
height
6.50* (0-20 in)
On a pivoting scale with Model 50-30 static weight,
measurement from carry roll to carriage height
centerline.
Note: Scale code dependent.
*Default value for Belt Scale code #1 shown.
4O # of load cells 2* (1-6) Quantity of load cells wired to the Micro-Tech.
Default value for Belt Scale code #1 shown.
The number of load cells is automatically fixed to a value
of 2 when Two A/D Channel is selected for scroll 1A
Type of scale.
The number of load cells is automatically fixed to a value
of 4 when Four A/D Channel is selected for scroll 1A
Type of scale.
5
Idler spacing
36* (2-999 in)
Spacing of “Scale Area” idlers.
*Default value for Belt Scale code #1 shown.
6
Conveyor angle
Degrees
0 (-35 - +35)
Incline of conveyor. A 10-44 (incline compensator) can
be installed for measurement of changing conveyor
inclines.
7
Load cell capacity
250 (1-50000 lb)
Rated capacity of a single load cell. On multiple load cell
scales each load cell will be of equal size.
Input ONLY capacity of one.
8
Load cell sens.
3.000 mV/V (0.5-
3.5)
Load cell mv/v rating.
Refer to label at end of load cell cable or the
applications data sheet from Thermo.
9A
Load cell #1 res.
350.000 Ohms
(10-2000)
Signal bridge resistance of load cell #1.
