High-Level Inputs (Two Channels)
Differential voltage.
 Input Range (Volts)
 0 to +5 V
 +1 to +5 V
 -5 to +5 V
Current (Requires Jumper Selection)
 Input Range (mA)
 0 to +20 mA
 +4 to 20 mA
 Converted Display (Volts)
 0 to +5 V
 +1 to +5 V
 Jumpers J1 and/or J2 are used to select 250 ohm resistance for the
Current inputs.
 Input impedance: 100 k nominal (differential)
 Maximum usable input voltage: 106% of full scale
 Non-isolated voltage
 Max. non-destructive input voltage: 12V peak
Current Outputs (Two Channels)
Here are the specifications.
 Optically isolated
 Isolated power source
 Output Range (mA)
 0 to 20 mA
 +4 to 20 mA
 Voltage output by adding an internal dropping resistor.
