Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-15
Register
Bit
Description
1
Low Load Scale # 2
0
HIGH RATE
Alarm
(2)
15
High Rate Scale # 1
14
High Rate Scale # 2
13
LOW RATE
12
Low Rate Scale # 1
11 Low Rate Scale # 2
10
HIGH SPEED
9
High Speed Scale # 1
8
High Speed Scale # 2
7
LOW SPEED
6
Low Speed Scale #1
5
Low Speed Scale #2
4
Warm Start
3
Cold Start
2
Power During Calibration
1
Calibration Time Elapsed (Single Scale)
0
Calibration Time Elapsed Scale # 1
Alarm
(3)
15 Calibration Time Elapsed Scale # 2
14
External Alarm 1
13
External Alarm 2
12
External Alarm 3
11 OVERFLOW TOTALIZER
10
Overflow Totalizer Scale #1
9
Overflow Totalizer Scale #2
8
AZT OVER LIMIT
7
AZT Over Limit Scale #1
6
AZT Over Limit Scale #2
5
BATCH DEVIATION
4
Batch Deviation Scale #1
3 Batch Deviation Scale #2
2
HW configuration Changed Slot 1
1
HW configuration Changed Slot 2
0
HW configuration Changed Slot 3
Alarm
(4)
15
HW configuration Changed Slot 4
14
Not Used
13
Not Used
12
Not Used
11
Math Error
10
Printer Error
9
Communication Error
8
Not Used
7 Profibus Error
6
ZERO LIMIT
5
Zero Limit Scale #1
4
Zero Limit Scale #2
3
AZT OVER LIMIT STEP
