Bit
Description
11
Input 4 - Digital Input Board
10
Input 3 - Digital Input Board
9
Input 2 - Digital Input Motherboard (Speed Input 2)
8
Input 1 - Digital Input Motherboard (Speed Input 1)
7
Input 8 - Digital 8In/8Out Board #1
6
Input 7 - Digital 8In/8Out Board #1
5 Input 6 - Digital 8In/8Out Board #1
4
Input 5 - Digital 8In/8Out Board #1
3
Input 4 - Digital 8In/8Out Board #1
2
Input 3 - Digital 8In/8Out Board #1
1
Input 2 - Digital 8In/8Out Board #1
0
Input 1 - Digital 8In/8Out Board #1
I/O (2)
15
Input 8 - Digital 8In/8Out Board #2
14
Input 7 - Digital 8In/8Out Board #2
13
Input 6 - Digital 8In/8Out Board #2
12
Input 5 - Digital 8In/8Out Board #2
11
Input 4 - Digital 8In/8Out Board #2
10
Input 3 - Digital 8In/8Out Board #2
9 Input 2 - Digital 8In/8Out Board #2
8
Input 1 - Digital 8In/8Out Board #2
7
Not Used
6
Output 5 - Motherboard Output
5 Output 4 - Digital Input Board
4
Output 3 - Digital Input Board
3
Output 2 - Digital Input Board
2
Output 1 - Digital Input Board
1
Not Used
0
Not Used
I/O (3)
15
Output 8 - Digital 8In/8Out Board #1
14
Output 7 - Digital 8In/8Out Board #1
13 Output 6 - Digital 8In/8Out Board #1
12
Output 5 - Digital 8In/8Out Board #1
11
Output 4 - Digital 8In/8Out Board #1
10
Output 3 - Digital 8In/8Out Board #1
9
Output 2 - Digital 8In/8Out Board #1
8
Output 1 - Digital 8In/8Out Board #1
7
Output 8 - Digital 8In/8Out Board #2
6
Output 7 - Digital 8In/8Out Board #2
5
Output 6 - Digital 8In/8Out Board #2
4
Output 5 - Digital 8In/8Out Board #2
3
Output 4 - Digital 8In/8Out Board #2
2
Output 3 - Digital 8In/8Out Board #2
1 Output 2 - Digital 8In/8Out Board #2
0
Output 1 - Digital 8In/8Out Board #2
I/O (4)
15
Not Used
14
Not Used
13
Not Used
