Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-35
Response Message
address xxx
function 06H
add hi xxx
add lo xxx
value hi xxx
value lo xxx
crc16 lo xxx
crc16 hi xxx
Example 6: Host Wants to Write the Batch Number
Batch number = 0
Address of Micro-Tech (Slave) = 1
Host (PLC) Slave (Micro-Tech)
01H →
06H
00H
5CH
00H
00H
49H
D8H →
← 01H
06H
00H
5CH
00H
00H
49H
← D8H
