Thermo Fisher Scientific Micro-Tech 9101/9201 Reference Manual, Rev J C-59
Configuration Parameters
Type
Parameter
Value
Remark
Writing data (Output)
Service Type
Write Assembly
(Cntrl Logix - Compact Logix)
May be different
Service Code
10 (hex)
Class
4 (hex)
Attribute
3 (hex)
Instance 70 (hex) - 112 (dec)
Length Size
82 (hex) - 130 (dec)
According data Table
Write Data Table
Register Name Comments
Register Start
Number
OffSet
Number Of trials BOTH 0 0
Command Scale 1 1 2
Last Key Pressed
BOTH
3
6
Batch Number
Scale 1
4
8
Batch Deviation Scale 1 5 10
Free Space Scale 1 6 12
Free Space
Scale 1
7
14
Free Space
Scale 1
8
16
Free Space Scale 1 9 18
Free Space Scale 1 10 20
Free Space
Scale 1
11
22
Free Space Scale 1 12 24
Free Space Scale 1 13 26
Free Space Scale 1 14 28
Free Space
Scale 1
15
30
Scale Capacity
Scale 1
16
32
Speed Capacity Scale 1 18 36
Load Cell Capacity Scale 1 20 40
Batch Setpoint
Scale 1
22
44
Batch Preset
Scale 1
24
48
Batch Preact Scale 1 26 52
Auto Zero Max Dev Scale 1 28 56
AZT step limit
Scale 1
30
60
Belt Warm Scale 1 32 64
High Rate Set Scale 1 34 68
Low Rate Set Scale 1 36 72
High Speed Set
Scale 1
38
76
Low Speed Set Scale 1 40 80
High Load Set Scale 1 42 84
Low Load Set Scale 1 44 88
