Configuring Layer 2 Multicast Multicast Filtering Configuration
User Guide 257
Figure 5-2 Configure Multicast Groups to Be Filtered
3) In the Bind Ports section, select your desired ports to be bound with the profile.
4) Click Save.
5.1.2 Configure Multicast Filtering for Ports
You can modify the mapping relation between ports and profiles in batches, and configure
the number of multicast groups a port can join and the overflow action.
The process for configuring multicast filtering for ports in IPv4 and IPv6 are similar. The
following introductions take configuring multicast filtering for ports in IPv4 as an example.
Choose the menu L2 FEATURES > Multicast > Multicast Filtering > IPv4 Port Config to
load the following page.
Note:
For IPv6, choose the menu L2 FEATURES > Multicast > Multicast Filtering > IPv6 Port Config.
Figure 5-3 Configure Multicast Filtering for Ports
