User Guide 788
RMON Configurations
Action Mode Specify the action for the switch to take when the event is triggered.
None: No action.
Log: The switch records the event in the log, and the NMS should initiate requests
to get notifications.
Notify: The switch sends notifications to the NMS.
Log & Notify: The switch records the event in the log and sends notifications to the
NMS.
3) Enter the owner name, and set the status of the entry. Click Apply.
Owner Enter the owner name of the entry with 1 to 16 characters.
Status Enable or disable the entry.
Enable: The entry is enabled.
Disable: The entry is disabled.
5.1.4 Configuring Alarm Group
Before you begin, complete configurations of Statistics entries and Event entries, because
the Alarm entries must be associated with Statistics and Event entries.
Choose the menu MAINTENANCE > SNMP > RMON > Alarm to load the following page.
Figure 5-4 Configuring the Alarm Entry
