User Guide 72
Managing System PoE Configurations (Only for Certain Devices)
Switch(config-if)#show power inline information interface gigabitEthernet 1/0/5
Interface Power(w) Current(mA) Voltage(v) PD-Class Power-Status
---------- -------- ----------- ---------- ----------- ----------------
Gi1/0/5 1.3 26 53.5 Class 2 ON
Switch(config-if)#end
Switch#copy running-config startup-config
6.2.2 Configuring the PoE Parameters Using the Profile
Follow these steps to configure the PoE profile:
Step 1 configure
Enter global configuration mode.
Step 2 power inline consumption
power-limit
Specify the maximum power the PoE switch can supply globally.
power-limit
: Specify the maximum power the PoE switch can supply.
For T1500-28PCT, the valid value ranges from 1 to 192 W. By default, the value is 192.
For TL-SG2210MP, the valid value ranges from 1 to 150 W. By default, the value is 150.
For TL-SG2210P, the valid value ranges from 1 to 58 W. By default, the value is 58.
Step 3 power profile
name
[ supply { enable | disable } [ priority { low | middle | high } [ consumption {
power-limit
| auto | class1 | class2 | class3 | class4 } ] ] ]
Create a PoE profile for the switch. In a profile, the PoE status, PoE priority and power limit
are configured. You can bind a profile to the corresponding port to quickly configure the PoE
function.
name
: Specify a name for the PoE profile. It ranges from 1 to 16 characters. If the name
contains spaces, enclose the name in double quotes.
enable | disable: Specify the PoE status for the profile. By default, it is enable.
low | middle | high: Select the priority level for the profile. When the supply power exceeds the
system power limit, the switch will power off PDs on low-priority ports to ensure stable running
of other PDs.
power-limit
| auto | class1 | class2 | class3 | class4: Select or enter the maximum power the
corresponding port can supply. The following options are provided: Auto represents that the
switch will assign a value of maximum power automatically. Class1 represents 4 W, Class2
represents 7 W, Class3 represents 15.4 W and Class4 represents 30 W or you can enter a
value manually. The value ranges from 1 to 300. It is in the unit of 0.1 watt. For instance, if you
want to configure the maximum power as 5 W, you should enter 50.
