Trango Systems, Inc. GigaPlus User Manual Rev 3.1 112

Figure 54 System Log

Config View

Config View allows complete display of the current system configuration. By selecting

the “config View” option from the pull down menu, then “submit, the display will be

shown. The window is scrollable and expandable on most browsers.
