Wireless Link Capacity
The table below shows the capacity of the system for each non-ACM speed setting. The
capacities for the ACM settings will be approximately 1-2% lower due to the additional
overhead of the ACM.
All capacities shown are in Mbps full duplex, meaning that the aggregate bidirectional
capacity is twice the number shown.
The capacities shown are also layer 2 using 1518 byte packets for IPV4, rounded to the
nearest Mbps. Layer 1 numbers will be higher, especially for small packets:
BW(MHz)
Symbol
Rate
(Msps)
QPSK
QAM16
QAM32
QAM64
QAM128
QAM256
4
3.75
6
9
15
18
21
23
5
4.3
8
12
19
24
27
31
7
5.6
10
20
25
31
36
40
8.33
7.2
13
26
33
40
46
52
10
8.32
15
30
37
46
53
60
12.5
10.8
20
40
49
60
70
78
14
12.2
22
45
55
67
78
88
20
17.42
31
63
78
96
111
126
25
21.8
39
80
99
120
140
160
28/30
26
47
95
118
142
167
192
40
34.82
63
128
159
192
225
256
50
43
78
157
195
238
277
318
55/56/80
49.5
90
181
225
275
320
365*
*375 Mbps when set to speed 80 qam256, with symbol rate 49.9 Msym/sec
Table 6 Max Link Capacity (Mbps) for non-ACM Speed Settings
