Trango Systems, Inc. GigaPlus User Manual Rev 3.1 209
1+1 Hot Standby Link Protection
Parameter
Specification
Failover Time
150 mSec typical
Guard Time
User configurable 10 to 60 seconds
Power
Parameter
Specification
Input Voltage Range
-40 to -72 VDC
Power Consumption
IDU: Max 35 Watts with all ports active
ODU: Typical 25 Watts, max 50 Watts
User Interfaces
Description
Specification
Ethernet Traffic Ports and/or In
Band Management (IBM)
ETH1 and ETH2: RJ45 Jack - 10/100/1000BaseT
ETH3 and ETH4: SFP - 1000BaseT for SFP Module:
SFP-GigE- C (1000BaseT)
SFP-GigE-S (1000BaseLX Single Mode Fiber)
SFP-GigE-M (1000BaseLX Multimode Fiber)
Out of Band Management (OBM)
RJ45 Jack- 10/100BaseT
T1/E1 Ports 1-8
RJ45 Jack
Alarm Inputs (2)
0-5 Volt high impedance CMOS level
Alarm Outputs (2)
DB9 Female, 50 Volt 1 Amp rated, Dry contact
PowerInput
3 Position latching screw terminal Block with locking screws
Console/Craft Port
DB9 Male(requires Serial Cable)
1+1 Redundancy Port
RJ45 Jack (requires CBLDAT-RIU3)
RSSI Alignment
BNC-Female (CBLDAT-RSSI recommended)
Reset IP/Config
Momentary Push Button on IDU front panel
Reboot System
Momentary Push Button on IDU front panel
Antenna
Slip-Fit Circular Waveguide for 7-40 GHz
Slip-Fit Rectangular Waveguide for 6 GHz
