directly to queues. In this mode, the proportion of time spent forwarding
the packets from each queue is proportional to the weight given to the
queue.
For example, If all queues are given a weight of 1, then there will be no
preferential treatment given to any one queue. If one queue is
subsequently given a value of 8, then that queue be emptied 8 times more
often than the queues with weight of 1.
This method allows some packets to go through from all queues but not all
high priority queue packets can be guaranteed to go through in the event
of saturation of the link capacity.
qos_info x displays the current DSCP mapping of DSCP field to priority for
Ethernet port x
EXAMPLE:
(CLI-config)# qos 2 3
qos map priority=2, queue=3
SUCCESS
(CLI-config)# qos
COS scheduling: strict
Priority 0: COS Queue = 0
Priority 1: COS Queue = 1
Priority 2: COS Queue = 3
Priority 3: COS Queue = 3
Priority 4: COS Queue = 4
Priority 5: COS Queue = 5
Priority 6: COS Queue = 6
Priority 7: COS Queue = 7
