Trango Systems, Inc. GigaPlus User Manual Rev 3.1 229
Appendix E – Part Numbers
GigaPlus HP ODU Sub-bands/Tuning Ranges
ODU, Part
Numbers
Description
TX Freq
Min*
(MHz)
TX Freq
Max*
(MHz)
Diplexer
Range
(MHz)
Max
Chan
Size
(MHz)
HP ODUs, 6 GHZ
HP2-06-0160-1A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 1A - High Band 6,540 6,600 60 56
HP2-06-0160-1B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 1B - High Band 6,700 6,760 60 56
HP2-06-0160-2A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 2A - High Band 6,580 6,640 60 56
HP2-06-0160-2B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 2B - High Band 6,740 6,800 60 56
HP2-06-0160-3A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 3A - High Band 6,620 6,680 60 56
HP2-06-0160-3B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 3B - High Band 6,780 6,840 60 56
HP2-06-0160-4A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 4A - High Band 6,660 6,710 50 50
HP2-06-0160-4B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 4B - High Band 6,820 6,870 50 50
HP-06-0240-1A ODU, HP 6Ghz,ETSI TR240, 1A - Low Band 5,925 6,025 100 56
HP-06-0240-1B ODU, HP 6Ghz, ETSI TR240, 1B - Low Band 6,175 6,275 100 56
HP-06-0240-2A ODU, HP 6Ghz, ETSI TR240, 2A - Low Band 6,000 6,100 100 56
HP-06-0240-2B ODU, HP 6Ghz, ETSI TR240, 2B - Low Band 6,250 6,350 100 56
HP-06-0240-3A ODU, HP 6Ghz, ETSI TR240, 3A - Low Band 6,075 6,175 100 56
HP-06-0240-3B ODU, HP 6Ghz, ETSI TR240, 3B - Low Band 6,325 6,425 100 56
HP2-06-0252-1A ODU, HP2 6Ghz, ANSI/ETSI TR252, 1A - Low Band 5,915.55 5,989.68 74 56
HP2-06-0252-1B ODU, HP2 6Ghz, ANSI/ETSI TR252, 1B - Low Band 6,167.59 6,241.72 74 56
HP2-06-0252-2A ODU, HP2 6Ghz, ANSI/ETSI TR252, 2A - Low Band 5,974.85 6,048.98 74 56
HP2-06-0252-2B ODU, HP2 6Ghz, ANSI/ETSI TR252, 2B - Low Band 6,226.89 6,301.02 74 56
HP2-06-0252-3A ODU, HP2 6Ghz, ANSI/ETSI TR252, 3A - Low Band 6,034.15 6,108.28 74 56
HP2-06-0252-3B ODU, HP2 6Ghz, ANSI/ETSI TR252, 3B - Low Band 6,286.19 6,360.32 74 56
HP2-06-0252-4A ODU, HP2 6Ghz, ANSI/ETSI TR252, 4A - Low Band 6,093.45 6,167.58 74 56
HP2-06-0252-4B ODU, HP2 6Ghz, ANSI/ETSI TR252, 4B - Low Band 6,345.49 6,419.62 74 56
HP-06-0252-1A ODU, HP 6Ghz, ANSI/ETSI TR252, 1A - Low Band 5,925 6,025 100 56
HP-06-0252-1B ODU, HP 6Ghz, ANSI/ETSI TR252, 1B - Low Band 6,175 6,275 100 56
HP-06-0252-2A ODU, HP 6Ghz, ANSI/ETSI TR252, 2A - Low Band 6,000 6,100 100 56
HP-06-0252-2B ODU, HP 6Ghz, ANSI/ETSI TR252, 2B - Low Band 6,250 6,350 100 56
HP-06-0252-3A ODU, HP 6Ghz, ANSI/ETSI TR252, 3A - Low Band 6,075 6,175 100 56
HP-06-0252-3B ODU, HP 6Ghz, ANSI/ETSI TR252, 3B - Low Band 6,325 6,425 100 56
HP2-06-0300-1A ODU, HP2 6Ghz, ETSI TR300, 1A - Low Band 5,850 5,946 96 56
HP2-06-0300-1B ODU, HP2 6Ghz, ETSI TR300, 1B - Low Band 6,150 6,246 96 56
HP2-06-0300-2A ODU, HP2 6Ghz, ETSI TR300, 2A - Low Band 5,918 6,014 96 56
HP2-06-0300-2B ODU, HP2 6Ghz, ETSI TR300, 2B - Low Band 6,218 6,314 96 56
HP2-06-0300-3A ODU, HP2 6Ghz, ETSI TR300, 3A - Low Band 5,986 6,082 96 56
HP2-06-0300-3B ODU, HP2 6Ghz, ETSI TR300, 3B - Low Band 6,286 6,382 96 56
HP2-06-0300-4A ODU, HP2 6Ghz, ETSI TR300, 4A - Low Band 6,054 6,150 96 56
HP2-06-0300-4B ODU, HP2 6Ghz, ETSI TR300, 4B - Low Band 6,354 6,450 96 56
