Trango Systems TrangoLINK GigaPlus - Appendix B - Product Specifications; Dimensions and Weight; Environmental; Emissions

Trango Systems, Inc. GigaPlus User Manual Rev 3.1 205
Appendix B – Product Specifications
Dimensions and Weight
Parameter
Specification
Size
IDU: 1.75 x 8.75 x 11.25 in
HP ODU: 10.5 x 10.5 x 3.5 in
HP1 ODU: 9.5 x 11.6 x 3.64 in
HP2 ODU: 10.9 x 9.4 x 3.6 in
Weight
IDU: 4.8 lbs/2.18 kg
HP ODU : 10.1 lbs/4.59 kg
HP1 ODU : 8.6 lbs/3.9 kg
HP2 ODU: 9.5 lbs/4.32 kg
Environmental
Parameter
Specification
Operating Temperature Range
IDU: -5 deg C to +55 deg C
ODU: -40 deg C to +65 deg C - Functional
ODU: -40 deg C to +55 deg C - Spec Compliant
Storage Temperature
-40 deg C to +75 deg C
Humidity
IDU : 95% Non condensing
ODU: 100% Condensing
Water resistance
IDU: NA
ODU:IP65 per EN 60529
Salt-Spray
IDU: NA
ODU: ETS 300 019-2-4 Class 4M5
Emissions
Parameter
Specification
ETSI Conducted Emissions
EN 55022 (2006) Class “A”
FCC Conducted Emissions
FCC 15.107 (a) Class “A”
