Trango Systems, Inc. GigaPlus User Manual Rev 3.1 75

1+1 Hot Standby IDU Installation

The installation of the 1+1 Hot Standby is similar to the 1+0 installation, except the

installation is repeated for the second standby unit which is mounted in the rack next to

the main unit. The dummy panel is removed in this case.

Figure 23 1+1 Hot Standby (IDUs) with CBLDAT-RIU3

CBLDAT-RIU3
