Trango Systems, Inc. GigaPlus User Manual Rev 3.1 149
By default, for each of the atpc power up/down command from the
remote unit, there will be 1 dB increment/decrement. The user may
specify this step size to maximum of 5 dB per command. The power
command to ODU is 1 dB at a time, but will go up to number of step size
per ATPC command.
The user is responsible for meeting legal/regulatory requirements for Tx
power.
ber
ber <0-99 duration in seconds>
Default: 1 second
Configuration Storage: Yes
ber without any parameter will display the current BER, LOCK, MSE, RSSI
values
BER applies to Ethernet Data only, and is based on CRC. FCs errors , and
only is functional when the datapattern is set to internal mode. It will
always be zero on live traffic (external datapattern).
bootimage toggle
bootimage upgrade <idu | odu>
Default: N/A
