Trango Systems, Inc. GigaPlus User Manual Rev 3.1 196

telnetd

SYNTAX

telnetd

telnetd <on | off>

Default: telnetd OFF.

Configuration Storage: Yes

telnetd without any parameter will display the current status for the

telnetd daemon

telnetd is a system-level command.

DESCRIPTION

Linux system command to start the telnetd daemon

temp

SYNTAX

temp

Default: N/A

Configuration Storage: No
