Trango Systems TrangoLINK GigaPlus - Radio Sensitivity

Trango Systems, Inc. GigaPlus User Manual Rev 3.1 208
Radio Sensitivity
Channel
Width
(MHz)
Symbol Rate
(Msps)
Receive Sensititivty (dBm) 6-26 GHz
QPSK
QAM
16
QAM
32
QAM
64
QAM
128
QAM
256
3.5
3
-96.6
-90.4
-86.4
-84
-80.9
-77.9
5
4.3
-94.4
-88.8
-84.8
-82.1
-79.0
-76.0
7
5.6
-93.3
-87.7
-83.7
-81.3
-78.2
-75.2
8.33
7.2
-92.7
-86.5
-82.5
-80.3
-77.5
-74.4
10
8.32
-92.2
-86.0
-82.0
-79.6
-76.5
-73.5
12.5
10.8
-91.3
-85.4
-81.1
-78.7
-75.4
-72.4
14
12.2
-90.5
-84.3
-80.3
-77.9
-74.8
-71.8
20
17.42
-89.0
-82.8
-78.8
-76.4
-73.3
-70.3
25
21.8
-88.1
-82.0
-78
-75.4
-72.3
-69.3
28/30
26
-87.3
-81.1
-77.1
-74.7
-71.6
-68.6
40
34.83
-86.0
-79.8
-75.8
-73.4
-70.3
-67.3
50
43
-85.1
-78.9
-74.9
-72.5
-69.4
-66.4
55/56/80
50
-84.5
-78.3
-74.3
-71.9
-68.8
-65.8*
*-63.8 dBm when set to speed 80 qam256
Channel
Width
(MHz)
Symbol Rate
(Msps)
Receive Sensititivty (dBm) 28-40 GHz
QPSK
QAM
16
QAM
32
QAM
64
QAM
128
QAM
256
3.5
3
-93.6
-87.4
-83.4
-81.0
-77.9
-74.9
5
4.3
-91.4
-85.8
-81.8
-79.1
-76.0
-73.0
7
5.6
-90.9
-84.7
-80.7
-78.3
-75.2
-72.2
8.33
7.2
-89.7
-83.5
-79.5
-77.3
-74.5
-71.4
10
8.32
-89.2
-83.0
-79.0
-76.6
-73.5
-70.5
12.5
10.8
-88.3
-82.4
-78.1
-75.7
-72.4
-69.4
14
12.2
-87.5
-81.3
-77.3
-74.9
-71.8
-68.8
20
17.42
-86.0
-79.8
-75.8
-73.4
-70.3
-67.3
25
21.8
-85.1
-79.0
-75
-72.4
-69.3
-66.3
28/30
26
-84.4
-78.1
-74.1
-71.7
-68.6
-65.6
40
34.83
-83.0
-76.8
-72.8
-70.4
-67.3
-64.3
50
43
-82.1
-75.9
-71.9
-69.5
-66.4
-63.4
55/56/80
50
-81.5
-75.3
-71.3
-68.9
-65.8
-62.8**
**-60.8 dBm when set to speed 80 qam256
