port eth <1-4> auto_negotiate <on| off>
port eth <1-4> dscp_source <1-63> <0-7>
port eth <1-4> duplex <half | full>
port eth <1-4> enable <on| off>
port eth <1-4> maxrate <0-1000>
port eth <1-4> pause <on| off>
port eth <1-4> priority <0-7>
port eth <1-4> speed <0-1000>
This command is used to individually set Ethernet port settings for auto
negotiation, dscp_source mapping, port enable/disable, speed, priority,
pause frame, duplex and max rate.
auto_negotiate must be enabled for Gigabit operation (default). For hard
setting of the speed to 100 Mbps or 10 Mbps, autonegotiate must be
turned off.
dscp_source is used to assign the DSCP field (0-63) in the IP packet to a
priority (0-7) and mirrors the web command.
maxrate will limit the incoming traffic on the port to the number set, in
Mbps.
pause will enable pause frames to be sent upon buffer full conditions and
only applies for Gigabit Ethernet operation.
priority will assign a priority to the internal tag used for smart mode to
condition traffic coming into the port that is untagged. This allows some
traffic shaping simply based on the port that the traffic is entering. If
tagged traffic comes into the port, the port priority setting will override
the COS field in the tagged traffic.
Note: speed/duplex/auto Negotiate is fixed for ge3/ge4 which are GigE
Fiber ports and these setting are not configurable
