Trango Systems, Inc. GigaPlus User Manual Rev 3.1 231
Outdoor Unit
Part Numbers
Description
TX Freq
Min*
(MHz)
TX Freq
Max*
(MHz)
Diplexer
Range
(MHz)
Max
Chan
Size
(MHz)
HP ODUs, 7 GHZ
HP2-07-0150-1A ODU, HP2 7Ghz, ANSI TR150, 1A 6,875 6,945 70 56
HP2-07-0150-1B ODU, HP2 7Ghz, ANSI TR150, 1B 7,025 7,095 70 56
HP2-07-0150-2A ODU, HP2 7Ghz, ANSI TR150, 2A 6,905 6,975 70 56
HP2-07-0150-2B ODU, HP2 7Ghz, ANSI TR150, 2B 7,055 7,125 70 56
HP2-07-0154-1A ODU, HP2 7Ghz, ETSI TR154, 1A 7,428 7,484 56 56
HP2-07-0154-1B ODU, HP2 7Ghz, ETSI TR154, 1B 7,582 7,638 56 56
HP2-07-0154-2A ODU, HP2 7Ghz, ETSI TR154, 2A 7,470 7,526 56 56
HP2-07-0154-2B ODU, HP2 7Ghz, ETSI TR154, 2B 7,624 7,680 56 56
HP2-07-0154-3A ODU, HP2 7Ghz, ETSI TR154, 3A 7,512 7,568 56 56
HP2-07-0154-3B ODU, HP2 7Ghz, ETSI TR154, 3B 7,666 7,722 56 56
HP1-07-0154-1A ODU, HP 7Ghz, ETSI TR154, 1A 7,428 7,484 56 56
HP1-07-0154-1B ODU, HP 7Ghz, ETSI TR154, 1B 7,582 7,638 56 56
HP1-07-0154-2A ODU, HP 7Ghz, ETSI TR154, 2A 7,470 7,526 56 56
HP1-07-0154-2B ODU, HP 7Ghz, ETSI TR154, 2B 7,624 7,680 56 56
HP1-07-0154-3A ODU, HP 7Ghz, ETSI TR154, 3A 7,512 7,568 56 56
HP1-07-0154-3B ODU, HP 7Ghz, ETSI TR154, 3B 7,666 7,722 56 56
HP2-07-0160-1A ODU, HP2 7Ghz, ETSI TR160, 1A 7,434 7,497 63 56
HP2-07-0160-1B ODU, HP2 7Ghz, ETSI TR160, 1B 7,594 7,657 63 56
HP2-07-0160-2A ODU, HP2 7Ghz, ETSI TR160, 2A 7,479 7,542 63 56
HP2-07-0160-2B ODU, HP2 7Ghz, ETSI TR160, 2B 7,639 7,702 63 56
HP2-07-0160-3A ODU, HP2 7Ghz, ETSI TR160, 3A 7,526 7,589 63 56
HP2-07-0160-3B ODU, HP2 7Ghz, ETSI TR160, 3B 7,686 7,749 63 56
HP1-07-0160-1A ODU, HP 7Ghz, ETSI TR160, 1A 7,433.5 7,496.5 63 56
HP1-07-0160-1B ODU, HP 7Ghz, ETSI TR160, 1B 7,593.5 7,656.5 63 56
HP1-07-0160-2A ODU, HP 7Ghz, ETSI TR160, 2A 7,478.5 7,541.5 63 56
HP1-07-0160-2B ODU, HP 7Ghz, ETSI TR160, 2B 7,638.5 7,701.5 63 56
HP1-07-0160-3A ODU, HP 7Ghz, ETSI TR160, 3A 7,526.0 7,589.0 63 56
HP1-07-0160-3B ODU, HP 7Ghz, ETSI TR160, 3B 7,686.0 7,749.0 63 56
HP2-07-0161-1A ODU, HP2 7Ghz, ETSI TR161, 1A 7,114 7,177 63 56
HP2-07-0161-1B ODU, HP2 7Ghz, ETSI TR161, 1B 7,275 7,338 63 56
HP2-07-0161-2A ODU, HP2 7Ghz, ETSI TR161, 2A 7,149 7,212 63 56
HP2-07-0161-2B ODU, HP2 7Ghz, ETSI TR161, 2B 7,310 7,373 63 56
HP2-07-0161-3A ODU, HP2 7Ghz, ETSI TR161, 3A 7,184 7,247 63 56
HP2-07-0161-3B ODU, HP2 7Ghz, ETSI TR161, 3B 7,345 7,408 63 56
HP2-07-0161-4A ODU, HP2 7Ghz, ETSI TR161, 4A 7,219 7,282 63 56
HP2-07-0161-4B ODU, HP2 7Ghz, ETSI TR161, 4B 7,380 7,443 63 56
HP2-07-0161-5A ODU, HP2 7Ghz, ETSI TR161, 5A 7,239 7,302 63 56
HP2-07-0161-5B ODU, HP2 7Ghz, ETSI TR161, 5B 7,400 7,463 63 56
HP2-07-0161-6A ODU, HP2 7Ghz, ETSI TR161, 6A 7,274 7,337 63 56
HP2-07-0161-6B ODU, HP2 7Ghz, ETSI TR161, 6B 7,435 7,498 63 56
HP2-07-0161-7A ODU, HP2 7Ghz, ETSI TR161, 7A 7,309 7,372 63 56
HP2-07-0161-7B ODU, HP2 7Ghz, ETSI TR161, 7B 7,470 7,533 63 56
HP2-07-0161-8A ODU, HP2 7Ghz, ETSI TR161, 8A 7,344 7,407 63 56
HP2-07-0161-8B ODU, HP2 7Ghz, ETSI TR161, 8B 7,505 7,568 63 56
HP2-07-0161-9A ODU, HP2 7Ghz, ETSI TR161, 9A 7,414 7,477 63 56
HP2-07-0161-9B ODU, HP2 7Ghz, ETSI TR161, 9B 7,575 7,638 63 56
HP2-07-0161-10A ODU, HP2 7Ghz, ETSI TR161, 10A 7,449 7,512 63 56
HP2-07-0161-10B ODU, HP2 7Ghz, ETSI TR161, 10B 7,610 7,673 63 56
HP2-07-0161-21A ODU, HP2 7Ghz, ETSI TR161, 21A 7,484 7,547 63 56
HP2-07-0161-21B ODU, HP2 7Ghz, ETSI TR161, 21B 7,645 7,708 63 56
HP2-07-0161-22A ODU, HP2 7Ghz, ETSI TR161, 22A 7,519 7,582 63 56
HP2-07-0161-22B ODU, HP2 7Ghz, ETSI TR161, 22B 7,680 7,743 63 56
HP2-07-0161-23A ODU, HP2 7Ghz, ETSI TR161, 23A 7,539 7,602 63 56
HP2-07-0161-23B ODU, HP2 7Ghz, ETSI TR161, 23B 7,700 7,763 63 56
HP2-07-0161-24A ODU, HP2 7Ghz, ETSI TR161, 24A 7,574 7,637 63 56
HP2-07-0161-24B ODU, HP2 7Ghz, ETSI TR161, 24B 7,735 7,798 63 56
HP2-07-0161-25A ODU, HP2 7Ghz, ETSI TR161, 25A 7,609 7,672 63 56
HP2-07-0161-25B ODU, HP2 7Ghz, ETSI TR161, 25B 7,770 7,833 63 56
HP2-07-0161-26A ODU, HP2 7Ghz, ETSI TR161, 26A 7,644 7,707 63 56
HP2-07-0161-26B ODU, HP2 7Ghz, ETSI TR161, 26B 7,805 7,868 63 56
