Configure MVR Group Address Table
Multicast > MVR > Group Address
Displays the groups that have been dynamically learned by the switch and allowed you
statically add MVR groups to the switch.
1. Log into your switch management page (see “Access your switch management page”
on page 11).
2. Click on Multicast, click on MVR, and click Group Address.
3. Click Add to a static MVR group address.
• Group Address: Enter the multicast group address to statically add to the table.
• Member – In the Available Port list, select the ports to statically assign for the
MVR multicast group. You can use the arrow buttons to add and
remove to the Selected port list.
Note: Multiple ports can be selected at the same time by holding the Shift or
Ctrl key.
4. Click Apply.
5. In the top right, click Save to save the configuration settings to NV-RAM/startup
configuration.
6. Click OK.
