Configure RMON Alarm Table
Management > RMON > Alarm
1. Log into your switch management page (see “Access your switch management page”
on page 11).
2. Click on Management, click on RMON, and click on Alarm.
3. Click "Add/Edit" button to Add/Edit an alarm. Review the settings.
Port
Specify the port for sampling
Counter
Specify the counter for sampling
● Drop Event: Total number of events received in
which the packets were dropped.
● Received Bytes (Octets): Octets.
● Received Packets: Number of packets.
● Broadcast Packets Received: Broadcast packets.
● Multicast Packets Received: Multicast packets.
● CRC and Align Error: CRC alignment error.
● Undersize Packets: Number of undersized
packets.
● Oversize Packets: Number of oversized packets.
● Fragments: Total number of packet fragment.
● Jabbers: Total number of packet jabber.
● Collisions: Collision.
● Frames of 64 Bytes: Number of packets size 64
octets.
● Frames of 65 to 127 Bytes: Number of packets
size 65 to 127 octets.
● Frames of 128 to 255 Bytes: Number of packets
size 128 to 255 octets.
● Frames of 256 to 511 Bytes: Number of packets
size 256 to 511 octets.
● Frames of 512 to 1023 Bytes: Number of packets
size 512 to 1023 octets.
● Frames Greater than 1024 Bytes: Number of
packets size 1024 to 1518 octets.
Sampling
Specify the sampling type.
● Absolute: The selected variable value is
compared directly with the thresholds at the end
of the sampling interval.
● Delta: The selected variable value of the last
sample is subtracted from the current value and
the difference is compared with the thresholds.
Interval
Specify the sampling interval.
Owner
Specify the owner for the sampling.
Trigger
Specify the type for the alarm trigger.
RISING
Item
Description
