Configure IPv4 ACL
ACL > IPv4 ACL
This section allows users to configure access control lists filtered based on IPv4 address.
1. Log into your switch management page (see “Access your switch management page”
on page 11).
2. Click on ACL and click on IPv4 ACL.
3. Review the settings below.
Item
Description
ACL Name
Input IPv4 ACL name.
ACL Name
Display IPv4 ACL name.
Rule
Display the number ACE rule of ACL.
Port
Display the port list that bind this ACL.
4. Click Apply.
5. In the top right, click Save to save the configuration settings to NV-RAM/startup
configuration.
6. Click OK.
