TRENDnet User’s Guide

TPE-3012LS / TPE-3018LS

133

ICMP Code

Select the type for ICMP code. Only available when protocol

is ICMP.

● Any: All codes are acceptable.

● User Defined: Enter an ICMP code to match.
