Number of packets that were dropped.
Number of packets received, including bad packets,
Multicast packets, and Broadcast packets.
Number of good Broadcast packets received. This number
does not include Multicast packets.
Number of good Multicast packets received.
Number of CRC and Align errors that have occurred.
Number of undersized packets (less than 64 octets)
received.
Number of oversized packets (over 1518 octets) received.
Number of fragments (packets with less than 64 octets,
excluding framing bits, but including FCS octets) received.
Number of received packets that were longer than 1632
octets. This number excludes frame bits, but includes FCS
octets that had either a bad FCS (Frame Check Sequence)
with an integral number of octets (FCS Error) or a bad FCS
with a non-integral octet (Alignment Error) number. A Jabber
packet is defined as an Ethernet frame that satisfies the
following criteria:
● Packet data length is greater than MRU.
● Packet has an invalid CRC.
● RX error event has not been detected.
Number of collisions received. If Jumbo Frames are enabled,
the threshold of Jabber Frames is raised to the maximum size
of Jumbo Frames.
Number of frames, containing 64 bytes that were received.
Frames of
65 to 127
Bytes
Number of frames, containing 65 to 127 bytes that were
received.
Frames of
128 to 225
Bytes
Number of frames, containing 128 to 255 bytes that were
received.
Frames of
256 to 511
Bytes
Number of frames, containing 256 to 511 bytes that were
received.
Frames of
512 to
1023 Bytes
Number of frames, containing 512 to 1023 bytes that were
received.
Frames
Greater
than 1024
Bytes
Number of frames, containing 1024 to 1518 bytes that were
received.
Clear the statistics for the selected ports.
View the statistics on the specified port.
