• IP Source Guard / IP-MAC-Port-VLAN binding
• Protected ports
• Port Security/MAC address learning restriction
Access Control List (ACL)
• MAC Address (VLAN ID, EtherType, 802.1p)
• IPv4 (IP Protocol, TCP/UDP Port, 802.1p, DSCP, TCP flag, ICMP type, ICMP
code)
Surveillance Mode (ONVIF)
• Surveillance mode GUI for simplified configuration and network monitoring
• Device discovery for ONVIF compliant devices such as IP cameras or NVRs
• Upload virtual maps
• Change IP camera IP address settings
• Upgrade IP camera firmware
• Change IP camera administrator user name and password
PoE
• PoE budget: 220W
• 802.3at: up to 30W per port (ports 1-16)
• PoE Mode A: Pins 1,2 and pins 3,6 for power
• PoE power scheduling
• PD alive check
• Over current/short circuit protection
Power
• Input: 100 – 240V AC, 50 – 60Hz, internal power supply
• Max. consumption: 14W (No PoE load)
Surge Protection
• 6kV (Ports 17 & 18)
Fan/Acoustics
• Quantity: 1 (Hot swappable)
• Noise Level: 60.1 dBA (max.)
MTBF
• 331,516 hours
Operating Temperature
• 0 – 40°C (32 – 104°F)
Operating Humidity
• Max. 90% non-condensing
Dimensions
• 440 x 195 x 44.45mm (17.3 x 9.8 x 1.74 in.)
• Rack mountable 1U height
Weight
• 2.93kg (6.45 lbs.)
Certifications
• CE
• FCC
• ETL
