TRENDnet User’s Guide

TPE-3012LS / TPE-3018LS

• Bandwidth Utilization – This section displays the current transmit and receive

bandwidth utilization per port by percentage in graphical format. The Refresh

Rate option allows you to select the interval that the bandwidth utilization data

is updated.
