Vaisala WINDCAP WMT700 Series User Manual

Appendix E. WMT700 NMEA
MWV Profile
E.1 Configurable Parameters
When the WMT700 NMEA MWV
profile is selected, you can set WMT700 to send messages
based on the configured automatic message interval or poll MWV message using the NMEA
Query command.
The following table shows the
configurable parameters and their allowed and default values
for the WMT700 NMEA MWV profile.
Table 74 Configurable Parameters for WMT700 NMEA MWV Profile
Parameter Default
Value
Profile-Specific Allowed
Values
Description
address
N/A String with 2 characters, for
example WI
Address for WMT700. The address must
consist of two capital letters A … Z
autoInt
1 0.25 ... 1000 Resolution:
0.25
Automatic message interval in seconds. Do
not select a message interval that is
shorter than the time it takes to send a
data message
autoPort
1 1 = COM1 port
2 = COM2 port
Serial port to which WMT700 sends
automatic data messages
autoSend
0 0 = Automatic messages
disabled
20 = WMT700 NMEA MWV
automatic data message
Automatic data message number. Selects
the data message format for automatic
messages
com1_protocol
0 11 = WMT700 NMEA MWV
protocol
Profile for serial port COM1
com2_protocol
0 11 = WMT700 NMEA MWV
protocol
Profile for serial port COM2
com2_interf
N/A 0 = RS-485
1 = RS-422
3 = RS-232
Interface for serial port COM2
wndAvg
1 0.25 … 3600 Resolution:
0.25
Averaging time for wind measurement in
seconds
wndOrientation
0 0 = Array facing up
1 = Array facing down
Orientation of the array of WMT700
Appendix E – WMT700 NMEA MWV Profile
193
