FIX30 is not compatible with adapter cables due to the small diameter of the mast.
4.11.6.2.1 Adapter Cable for WS425 Serial Output
The Adapter Cable for WS425 Serial (227569SP) can be used with the WS425 cables
ZZ45203 and 010411.
The following table lists the adapter pin-outs and signal descriptions as they appear on their
user guides for both WMT700 and WS425 connectors.
Table 35 Pin-Outs for WS425 Serial Adapter Cable (227569SP)
WMT700
Connector Pin
WMT700 Signal
Description
WS425
Connector Pin
WS425 Signal
Description
WS425
Wire Color
1 Operating Power Supply 11 +12 VDC Brown
3 COM2: Rx-/ RS232RX 10 Data in (RxD) (R-) (RT-) Blue
4 COM2: Tx-/ RS232TX 9 Data out (TxD) (T‑) (RT-) Red
5 Heater Power Supply 16 +36 VDC Gray/Pink
7 Heater Power Supply Ground 3 GND Green
10 COM2: Communications
Ground
8 GND Yellow
11 Operating Power Supply
Ground
1 GND Black
14 COM2: Tx+ 12 Data out (T+) (RT+) White
15 COM2: Rx+ 14 Data in (R+) (RT+) Pink
The Adapter Cable for WS425 Serial (227569SP) does not support SDI-12 operation.
4.11.6.2.2 Adapter Cable for WS425 Analog Frequency Output
The Adapter Cable for WS425 Analog Frequency Output (227570SP) can be with the
WS425 cable ZZ45204. The following table lists the adapter pin-outs and signal
descriptions as they appear on their user guides for both WMT700 and WS425 connectors.
Chapter 4 – Installation
95
