Vaisala WINDCAP WMT700 Series - 4.11.7 Powering in Retrofit Installations

Table 36 Pin-Outs for WS425 Analog Frequency Output Adapter Cable
WMT700
Connector Pin
WMT700 Signal
Description
WS425 Connector
Pin
WS425 Signal
Description
WS425
Wire Color
1 Operating Power
Supply
11 +12 VDC Brown
2 Analog Output AOUT2,
Wind Direction
13 WD Vout Gray
5 Heater Power Supply 16 +36 VDC Gray/Pink
7 Heater Power Supply
Ground
3 GND Green
11 Operating Power
Supply Ground
1 GND Black
12 Analog Output Ground 8 GND Yellow
13 Analog Output AOUT1,
Wind Speed
14 WS Fout Pink
17 Reference Input for
AOUT2
12 WD Vref in White
4.11.6.2.3 Adapter Cable for WS425 Analog Voltage Output
The Adapter Cable for WS425 Analog Voltage Output (227571SP) can be used with the
WS425 cable ZZ45204. The following table lists the adapter pin-outs and signal
descriptions as they appear on their user guides for both WMT700 and WS425 connectors.
Table 37 Pin-Outs for WS425 Analog Voltage Output Adapter Cable
WMT700
Connector Pin
WMT700 Signal
Description
WS425 Connector
Pin
WS425 Signal
Description
WS425 Wire
Color
1 Operating Power Supply 11 +12 VDC Brown
2 Analog Output AOUT2,
Wind Direction
13 WD Vout Gray
5 Heater Power Supply 16 +36 VDC Gray/Pink
7 Heater Power Supply
Ground
3 GND Green
11 Operating Power Supply
Ground
1 GND Black
12 Analog Output Ground 8 GND Yellow
13 Analog Output AOUT1,
Wind Speed
15 WS Vout Violet
17 Reference Input for
AOUT2
12 WD Vref in White
WMT700 User Guide M211095EN-H
96
