2.3.5 Digital Communication Profile
Ordering option 5 defines the used communication protocol. WS425 options are usable and
backwards compatible when replacing a WS425 sensor with a WMT700 unit. Other
application or
customer-specific user profiles are also available.
Table 9 Digital Communication Profile
Option Communication Profile
0 WMT70 - default mode 9600, 8, N, 1 Polled
1 WS425 - ASCII 2400, 8, N, 1 Polled
2 WS425 - NMEA Extended (v
0183)
9600, 8, N, 1 Auto send 1/s
3 WS425 - SDI-12 (v 1.3) 1200, 7, E, 1 Polled
4 WS425 - ASOS 2400, 8, N, 1 Polled
5 ROSA - MES12 9600, 8, N, 1 Polled
8 AWS520 - NMEA Extended (v
0183)
4800, 8, N, 1 Auto send 1/s
A MARINE1 (v 0183) 4800, 8, N, 1 Auto send 1/s
2.3.6 Digital Communication Units
Ordering option 6 oers four dierent digital communication options.
Table 10 Digital Communication Units
Option Unit Used
A Meters per second
B Knots
C Miles per hour
D Kilometers per hour
2.3.7 Analog Output Signal for Wind Speed Channel
Ordering option 7 can be disabled or factory-configured for 8 dierent modes. WS425
options are usable and backwards compatible when replacing WS425 sensor with a
WMT700 unit.
