Appendix D. Configuration
Parameter Descriptions
Table 73 Configuration Parameter Descriptions
Parameter Name Default
Value
Allowed Values Units Description
address
A String with a
maximum of 40
characters.
Address for WMT700. Note
that the SDI12, ASCII, NMEA
Extended, ASOS, and MES12
profiles use the first character
only. SDI-12 only uses digits 1 …
9.
aout1erraout2err
1000 0 … 32000 V, A, Hz, % Value for AOUT1 and AOUT2
analog output if wind
measurement fails.
aout1_gaout2_g
1 0 ... 100 Gain for AOUT1 (wind speed)
and AOUT2 (wind direction)
aout1_oaout2_o
0 -10000 … 10000 Oset for AOUT1 and AOUT2
aout1maxvaout2maxv
32000 0 … 32000 V, A, Hz, % Analog output maximum value
for AOUT1 and AOUT2. The
output is fixed to this value.
The unit depends on analog
output mode.
aout1minvaout2minv
0 0 … 32000 V, A, Hz, % Analog output minimum value
for AOUT1 and AOUT2. The
output is fixed to this value.
The unit depends on the
analog output mode.
aout1mode
3 0 = Current
1 = Voltage
2 = Frequency
3 = Disabled
Analog output mode for
AOUT1.
aout2mode
7 4 = Current
5 = Voltage
6 =
Potentiometer
7 = Disabled
Analog output mode for
AOUT2.
autoInt
1 0.25 ... 1000
Resolution: 0.25
s Automatic message interval in
seconds. This parameter
aects both serial
communication and analog
output. Do not select a
message interval that is
shorter than the time it takes
to send a data message.
