Installation Pipe System
TITANUS
MICRO·SENS
®
146
06/13
There are two fixing points for the plastic pipe clip CLIC-PA when installing
the pipes:
Position 1 (first locking into place)
Fixes the pipe so that a linear expansion is possible (used in deep freeze ar-
eas, if necessary).
Position 2 (second locking into place)
Fixes the pipe and avoids linear expansions.
Pipe Clips for ø 25 mm Type
standard pipe clips pipe clip
type NG 23 (ø 25 mm)
pipe clips for areas with high
temperature differences and
deep freeze areas
plastic pipe clip
type CLIC-PA (ø 25 – 28 mm)
pipe clips for deep-freeze areas and high rack
storage areas
spring steel clip type SNAP CLIP SC
(for profiles 1-4 mm)
spring steel clip type SNAP CLIP SC
(for profiles 4-7 mm)
spring steel clip type SNAP CLIP SC
(for profiles 8-12 mm)
